NS P/N	3 dB Bandwidth (Min.) (KHz)	Insertion Loss (Max.)	BPF Analysis Link	BPF Case Link
20700-4-3	3.0	5 dB	20700-4-3	Click on the link below to view case options Case Options
20700-4-5	5.0	5 dB	20700-4-5
20700-4-6	6.0	5 dB	20700-4-6
20700-4-7.5	7.5	5 dB	20700-4-7.5
20700-4-10	10.0	5 dB	20700-4-10
20700-4-12.5	12.5	5 dB	20700-4-12.5
20700-4-15	15.0	5 dB	20700-4-15
20700-4-20	20.0	4 dB	20700-4-20
20700-4-22.5	22.5	4 dB	20700-4-22.5
20700-4-25	25.0	4 dB	20700-4-25
20700-4-30	30.0	4 dB	20700-4-30
20700-4-35	35.0	4 dB	20700-4-35
20700-4-37.5	37.5	4 dB	20700-4-37.5
20700-4-40	40.0	4 dB	20700-4-40
20700-4-45	45.0	4 dB	20700-4-45
20700-4-50	50.0	4 dB	20700-4-50
20700-4-60	60.0	4 dB	20700-4-60
20700-4-65	65.0	4 dB	20700-4-65
20700-4-70	70.0	4 dB	20700-4-70
20700-4-75	75.0	4 dB	20700-4-75
20700-4-100	100.0	4 dB	20700-4-100
20700-4-128	128.0	5 dB	20700-4-128
20700-4-175	175.0	5 dB	20700-4-175
20700-4-200	200.0	6 dB	20700-4-200

NETWORK SCIENCES 70.0 MHz BANDPASS FILTER SERIES

Network Sciences offers a complete line of 70 MHz 4 pole filters. These filters are compact, robust, & a cost effective solution for your 70 MHz bandpass application. This filter series features 3 dB bandwidths from 3 kHz to 40 MHz. This 70 MHz series features low insertion loss, excellent selectivity, environmental stability, with leaded & surface mount enclosure options.

3 dB bandpass ripple …………………….……

40 dB / 3 dB Shape Factor ………….……….

Group delay …………………………….….…..

Return loss ………………………………….….

Source & Load Impedance ……………………

Operating Temperature ……………………….

Enclosure ………………………………….…...

1 dB max.

2.75/ 1.0 max

(See BPF analysis link for typical values)

50 ohm ± 5.0%

20° C to +70° C (Insertion loss below may increase 1 dB max.)

See enclosure options link

Note: The following additional options are available upon request

1.) Any 3 dB bandwidth is available between 3 kHz & 40 MHz.

2.) Extended operating temperature ranges are available

			Note: The below links are .PDF files
NS P/N	3 dB Bandwidth (Min.) (MHz)	Insertion Loss (Max.)	BPF Analysis Link	BPF Case Link
10700-4-1	1.0	dB		Click on the link below to view case options Case Options
10700-4-2.5	2.5	6 dB	10700-4-2.5
10700-4-4	4.0	5 dB	10700-4-4
10700-4-5	5.0	4 dB	10700-4-5
10700-4-7.5	7.5	3 dB	10700-4-7.5
10700-4-10	10.0	3 dB	10700-4-10
10700-4-15	15.0	3 dB	10700-4-15
10700-4-20	20.0	3 dB	10700-4-20
10700-4-30	30.0	2 dB	10700-4-30
10700-4-40	40.0	2 dB	10700-4-40
